CORSAIR - CORSAIR RMx Series RM850X SHIFT

Power supply (internal) - ATX12V 3.0/ EPS12V 2.92 - 80 PLUS Gold - AC 100-240 V - 850 Watt - North America

CORSAIR
CP-9020252-NA
0840006653790
N/A
New

Price:

Total Available: 0

Product Description

Additional Details

What's Included

Specifications

Main Specifications
Product Description CORSAIR RMx Series RM850X SHIFT - power supply - 850 Watt
Device Type Power supply - internal
Specification Compliance ATX12V 3.0/ EPS12V 2.92
80 PLUS Certification 80 PLUS Gold
Weight 1.7 kg
Localization North America
Input Voltage AC 100-240 V
Output Voltage +3.3, +5, +12 V
Power Capacity 850 Watt
Output Current +3.3V - 20 A ¦ +5V - 20 A ¦ +12V - 70.8 A ¦ +5VSB - 3 A
Output connectors 1 x power 24 pin ATX with detachable 4 pin section ¦ 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 1 x 12VHPWR ¦ 2 x 2 x 8 pin PCI Express power with detachable 2 pin section ¦ 2 x 8 pin PCI Express power with detachable 2 pin section ¦ 12 x 15 pin Serial ATA power ¦ 8 x 4 pin internal power
Modular Cable Management Yes
Cooling System 140 mm fan
Included Accessories Cable ties, mounting screw
Dimensions (WxDxH) 15 cm x 16 cm x 8.6 cm
Manufacturer Warranty 10-year warranty
General
Device Type Power supply - internal
Specification Compliance ATX12V 3.0/ EPS12V 2.92
PSU Form Factor ATX
Localization North America
Manufacturer Warranty
Service & Support Limited warranty - 10 years
Miscellaneous
Included Accessories Cable ties, mounting screw
Cables Included AC input cable ¦ Power 24 pin ATX modular cable 61 cm ¦ 16-pin 12VHPWR power cable 65 cm ¦ 2 x 2x 8 pin PCI Express power with detachable 2 pin section modular cable ¦ 2 x 8 pin PCI Express power with detachable 2 pin section modular cable 65 cm ¦ Power 8 pin EPS12V with detachable 4 pin ATX12V section modular cable 65 cm ¦ 3 x power 15 pin SATA cable 80 cm ¦ 2 x 4 pin internal power cable 75 cm
MTBF 100,000 hours
Cooling System 140 mm fan
Features Overheat protection, overcurrent protection, overvoltage protection, overpower protection, short-circuit protection, DC-DC technology, Zero RPM fan mode, fluid dynamic bearing cooling fan, fully modular, LLC resonant converter technology, Modern Standby compatible, side connections
Compliant Standards EMC, RoHS, LVD, EN/IEC 63000:2018, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN IEC 62368-1:2020+A11:2020, EN IEC 61000-3-2:2019+A1:2021
Power Device
Input Voltage AC 100-240 V
Frequency Required 47 - 63 Hz
Power Output Connectors Details 1 x power 24 pin ATX with detachable 4 pin section ¦ 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 1 x 12VHPWR ¦ 2 x 2 x 8 pin PCI Express power with detachable 2 pin section ¦ 2 x 8 pin PCI Express power with detachable 2 pin section ¦ 12 x 15 pin Serial ATA power ¦ 8 x 4 pin internal power
Output Voltage +3.3, +5, +12 V
Power Capacity 850 Watt
Output Current +3.3V - 20 A ¦ +5V - 20 A ¦ +12V - 70.8 A ¦ +5VSB - 3 A
Modular Cable Management Yes
80 PLUS Certification 80 PLUS Gold
Dimensions & Weight
Width 15 cm
Depth 16 cm
Height 8.6 cm
Weight 1.7 kg
Dimensions & Weight (Shipping)
Shipping Width 21.4 cm
Shipping Depth 30.2 cm
Shipping Height 12.9 cm
Shipping Weight 3.3 kg
